Automate hardware specifications#
Tutorial: videocam
If you found this video helpful, you can find more at Tutorials Home.
Overview#
Note
For details around the open source software components used in Automate, see the Open Source License Usage Guide.
Virtualized hardware and resource oversubscription#
It is recommended that no more than two Unified nodes and one Web Proxy node be run on a physical server (VM server) and that the disk subsystems are unique for each Unified node.
Automate virtual machines should maintain a 1:1 ratio between virtual RAM and Disk hardware and physical hardware, in other words:
1 GB of virtual RAM (vRAM) must map to 1 GB of physical RAM
1 GB of virtual Disk (vDisk) storage must map to 1 GB of physical storage
For virtual CPU (vCPU), hyper-threading is supported.
Unified node hardware specifications#
Single-node cluster (cluster-of-one) hardware specification#
This section provides the virtual machine specification for a single node cluster deployment topology in Automate.
For details on supported virtual machine platforms:
For supported virtual machine platform versions, refer to the Compatibility Matrix
Virtual machine requirements are specified in the table below.
Node type |
Quantity |
Memory |
CPU |
Disk |
Network |
|---|---|---|---|---|---|
Single node cluster |
1 |
32 GB with 32 GB reservation |
4 vCPU @ 2 GHz with 4000 MHz reservation |
Total: 440 GB as allocated below. 370 GB partitioned:
70 GB database disk to be added after upgrade or installation. Refer to the Upgrade Guide with ISO and Template or Installation Guide. |
1 Gbit/s minimum |
Note
From release 24.1, allowance should be made for an additional 70GB database disk to be added after upgrade or installation. This disk will be used for Insights sync.
Refer to the Upgrade Guide with ISO and Template or Installation Guide and Add disks in the AWS or MS Azure cloud hosted platform.
If memory allocations are customized, ensure that the memory reservation remains equal to the allocated memory in order to prevent possible negative side-effects due to memory reclamation.
The maximum number of users for a single node cluster is 50,000.
Multinode cluster hardware specification#
For details on supported virtual machine platforms:
For supported virtual machine platform versions, refer to the Compatibility Matrix
Virtual machine requirements are specified in the table below.
Node type |
Quantity |
Memory |
CPU |
Disk |
Network |
|---|---|---|---|---|---|
Unified |
4 or 6 |
32 GB with 32 GB reservation |
4 vCPU @ 2 GHz with 4000 MHz reservation |
Total: 440 GB as allocated below. 370 GB partitioned:
70 GB database disk to be added after upgrade or installation. Refer to the Upgrade Guide with ISO and Template or Installation Guide. |
1 Gbit/s minimum |
WebProxy |
2 |
4 GB with 4 GB reservation |
2 vCPU @ 2 GHz with no reservation |
70 GB partitioned:
|
1 Gbit/s minimum |
Note
From release 24.1, allowance should be made for an additional 70GB database disk to be added after upgrade or installation. This disk will be used for Insights sync.
Refer to the Upgrade Guide with ISO and Template or Installation Guide and Add disks in the AWS or MS Azure cloud hosted platform.
If memory allocations are customized, ensure that the memory reservation remains equal to the allocated memory in order to prevent possible negative side-effects due to memory reclamation.
The OS disk requirement is fixed and logs are rotated to ensure that 10 GB is sufficient. 40 GB for applications is a generous allocation and does not scale with the number of users.
The Database storage partition is sized to support 250 K users. Database backups are compressed and the partition is sized to ensure that sufficient space available to support backup of 250 GB database.
Note
To change the TRANSACTION_LOG cap size to greater than 10GB at larger providers for operational reasons,
for example for diagnostics and a longer transaction replay window, the
voss db_collection_cap TRANSACTION_LOG <10-50GB> command can be used
from the command line.
Refer to Database Commands for more details.
The resize operation will impact the usage on the disk size allocated for the database (typically, 250GB is reserved upon installation). Consider a larger database disk size allocation upon installation if a larger cap size is set.
The backup disk should be Thick Provisioned and Eager Zeroed for better performance immediately after installation.
Web Proxies are optional, but if Web Proxies are used, then they form part of the cluster to allow sharing of static data and other content as needed (for example, themes).
2 Node cluster hardware specification#
For details on supported virtual machine platforms:
For supported virtual machine platform versions, refer to the Compatibility Matrix
Virtual machine requirements are specified in the table below.
Node type |
Quantity |
Memory |
CPU |
Disk |
Network |
|---|---|---|---|---|---|
Unified |
= 2 |
32 GB with 32 GB reservation |
4 vCPU @ 2 GHz with 4000 MHz reservation |
Total: 440 GB as allocated below. 370 GB partitioned:
70 GB database disk to be added after upgrade or installation. Refer to the Upgrade Guide with ISO and Template or Installation Guide. |
1 Gbit/s minimum |
WebProxy |
>= 0 |
4 GB with 4 GB reservation |
2 vCPU @ 2 GHz with no reservation |
70 GB partitioned:
|
1 Gbit/s minimum |
For Memory and CPU, the Resource Allocation Reservation on VMware should correspond with these requirements.
Note
From release 24.1, allowance should be made for an additional 70GB database disk to be added after upgrade or installation. This disk will be used for Insights sync.
Refer to the Upgrade Guide with ISO and Template or Installation Guide and Add disks in the AWS or MS Azure cloud hosted platform.
If memory allocations are customized, ensure that the memory reservation remains equal to the allocated memory in order to prevent possible negative side-effects due to memory reclamation.
Modular cluster hardware specifications#
Multinode modular cluster hardware specification#
For details on supported virtual machine platforms:
For supported virtual machine platform versions, refer to the Compatibility Matrix
Virtual machine requirements are specified in the table below.
Node type |
Quantity |
Memory |
CPU |
Disk |
Network |
|---|---|---|---|---|---|
Application |
3 |
32 GB with 32 GB reservation |
4 vCPU @ 2 GHz with 4000 MHz reservation |
70 GB partitioned:
|
1 Gbit/s minimum |
Database |
3 |
32 GB with 32 GB reservation |
4 vCPU @ 2 GHz with 4000 MHz reservation |
Total: 440 GB as allocated below. 370 GB partitioned:
70 GB database disk to be added after upgrade or installation. Refer to the Upgrade Guide with ISO and Template or Installation Guide. |
1 Gbit/s minimum |
WebProxy |
2 |
4 GB with 4 GB reservation |
2 vCPU @ 2 GHz with no reservation |
70 GB partitioned:
|
1 Gbit/s minimum |
Note
From release 24.1, allowance should be made for an additional 250GB database disk to be added after upgrade or installation. This disk will be used for Insights sync.
Refer to the Upgrade Guide with ISO and Template or Installation Guide and Add disks in the AWS or MS Azure cloud hosted platform.
If memory allocations are customized, ensure that the memory reservation remains equal to the allocated memory in order to prevent possible negative side-effects due to memory reclamation.
The OS disk requirement is fixed and logs are rotated to ensure that 10 GB is sufficient. 40 GB for an applications role node is a generous allocation and the size will not have to be increased with the number of users.
The Database storage partition is sized to support 250 K users. Database backups are compressed and the partition is sized to ensure that sufficient space is available to support backup of 250 GB database.
Note
To change the TRANSACTION_LOG cap size to greater than 10GB at larger providers for operational reasons, for example for diagnostics, the voss db_collection_cap TRANSACTION_LOG <10-50GB> command can be used from the command line.
Refer to Database Commands for more details.
The resize operation will impact the usage on the size of the disk allocated for the database (typically, 250GB is reserved upon installation). Consider a larger database disk size allocation upon installation if a larger cap size is set.
The backup disk should be Thick Provisioned and Eager Zeroed for better performance immediately after installation.
Web Proxies are optional, but if Web Proxies are used, then they form part of the cluster to allow sharing of static data and other content as needed (for example, themes).
Add disks in the AWS or MS Azure cloud hosted platform#
The steps below are required to add a disk that provides for
the Insights database in release 24.1 - that should then be assigned to the insights-voss-sync:database
mount point (refer to the final step in the Upgrade Guide with ISO and Template for your topology).
AWS#
Create the EBS Volumes for each DB node in the Amazon EC2 console.
Go to EC2 > Volumes > Create volume
For Volume settings, enter:
Volume type: Provisioned IOPS SSD (io2)
Size (GiB): 70GB
IOPS: 750
For Availability Zone:
Create 3 volumes in each of the zones (for example: us-east-1a, us-east-1b, us-east-1c)
Attach the newly created volumes to each of the database nodes.
Go to EC2 > Volumes > volume_id > Attach volume
Instance: Select the database instance within the same corresponding az
Device Name:
/dev/sde(This will display asxvdein drives list)
Microsoft Azure#
In the Microsoft Azure portal, search for Virtual Machines
Select each of the database nodes
Select Disk under Properties
Click Create and attach a new disk.
LUN: Next available
Disk Name: Label according to your recommended naming convention
Storage Type: Premium SSD LRS
Size: 70GB
Encryption: Set according to your requirements
Host Caching: Read/Write
